valor plus remote control manual

Inserting Batteries in the Remote Control Receiver

To ensure proper operation, begin by inserting alkaline batteries into both the remote control receiver and the handset. Locate the receiver near the control valve and open the battery compartment. Carefully place the batteries, making sure they are securely seated and properly aligned with the terminals. Replace the compartment cover tightly to avoid any obstructions. Similarly, insert fresh alkaline batteries into the remote control handset, following the same alignment and securement steps. Avoid using damaged or low-power batteries, as this may affect performance. Once the batteries are installed, the system is ready for synchronization. This step is crucial for initial setup and ensures that the remote control functions correctly with the fireplace system.

Synchronizing the Remote Control Handset and Receiver

To synchronize the remote control handset and receiver, start by ensuring both devices are powered on. Locate the ON-OFF button on the receiver and press and hold it until the fireplace and pilot flame shut off. This step prepares the system for synchronization. Next, press and hold both the high flame and timer buttons on the remote control handset simultaneously for approximately 3-5 seconds. You will hear a beep, indicating successful synchronization. Once synchronized, the remote control will communicate with the receiver, allowing you to control the fireplace and its features seamlessly. If synchronization fails, repeat the process, ensuring the buttons are pressed firmly and held for the full duration. Proper synchronization is essential for the remote control to function correctly and control the fireplace’s operations effectively. After successful synchronization, test the remote by adjusting the flame or lighting to confirm it is working as expected.

Operating Modes of the Valor Plus Remote Control

The Valor Plus Remote Control offers three primary operating modes: Manual Mode, Temperature Mode, and Timer Mode. These modes allow you to control flame height, set temperature preferences, or schedule operations, ensuring a customized fireplace experience tailored to your needs.

Manual Mode Operation

In Manual Mode, you can directly control your fireplace’s basic functions using the Valor Plus Remote Control. To activate this mode, press the ON/OFF button until the fireplace turns on. Use the High Flame and Low Flame buttons to adjust the flame height to your preferred level. Pressing the High Flame button increases the flame, while the Low Flame button decreases it. For lighting control, press the Light button to toggle the overhead lights on or off.

• Turn the fireplace on/off with the ON/OFF button.
• Adjust flame height using High Flame and Low Flame buttons.
• Control lighting with the Light button.
• Press the Low Flame button to shut off the pilot light if needed.

Manual Mode provides immediate control, ideal for quick adjustments without scheduling or temperature settings. Refer to the remote’s buttons for intuitive operation.

Temperature Mode Configuration

To configure the Temperature Mode on your Valor Plus Remote Control, follow these steps. This mode allows you to set a desired temperature for your fireplace, ensuring consistent comfort in your room. Press and hold the Set button until the display flashes, indicating the remote is ready for temperature adjustment.

• Use the High Flame and Low Flame buttons to adjust the target temperature.
• Once the desired temperature is set, press the Set button to confirm.
• The remote will now regulate the fireplace to maintain the selected temperature.
• The display will show the current room temperature and the setpoint.

For scheduling, press and hold the Set button again to access the timer and clock settings. Choose between Fahrenheit or Celsius by pressing the High Flame button during the initial setup. This mode ensures your fireplace operates efficiently while maintaining your desired temperature. Refer to the manual for advanced customization options.

Once configured, the remote will automatically adjust the flame height to maintain the set temperature, providing a convenient and energy-efficient experience.

Timer Mode Setup and Usage

The Timer Mode on your Valor Plus Remote Control allows you to schedule fireplace operation for convenience and energy efficiency. To set up the timer, press and hold the Set button until the display flashes, then use the High Flame and Low Flame buttons to select your desired start and end times.

• Press the Set button to toggle between hours and minutes.
• Use the High Flame button to increase the timer value and the Low Flame button to decrease it.
• Once your timer is set, press the Set button to confirm.
• The remote will activate the fireplace at the scheduled time and turn it off when the timer expires.

For countdown functionality, press and hold the OFF button until you hear a beep, then adjust the timer using the flame buttons. The display will show the remaining time. Timer Mode is ideal for maintaining a cozy atmosphere without constant monitoring. Always refer to the manual for additional customization options and troubleshooting tips.

Advanced Features of the Valor Plus Remote Control

The Valor Plus Remote Control offers advanced features like flame height adjustment, lighting control, and timer functions. Use the high and low flame buttons to customize settings. Enable childproofing features for added safety and convenience.

Flame Height Adjustment Using High and Low Flame Buttons

The Valor Plus Remote Control allows you to adjust the flame height effortlessly using the high and low flame buttons. To increase the flame height, press the high flame button. Each press will gradually raise the flames, providing more heat and a larger fire display. Conversely, pressing the low flame button will decrease the flame height, reducing both the visual size of the flames and the heat output. For precise control, press and hold the buttons to achieve the desired flame level. Ensure the remote is synchronized with the receiver for proper function. If issues arise, check battery levels or resynchronize the system. This feature enhances both the aesthetic and functional experience of your fireplace, offering customizable comfort at your fingertips.

Lighting Control and Adjustment Options

The Valor Plus Remote Control offers convenient lighting control, enhancing your fireplace experience. Use the remote to turn the overhead lighting on or off with the press of a button. Adjust the brightness to create the perfect ambiance for any setting. The lighting control feature is accessed through the remote handset, allowing you to customize the visual appeal of your fireplace without physical adjustments. To activate the lighting, press and hold the designated button until the desired brightness is achieved. For optimal performance, ensure the remote is synchronized with the receiver. Note that lighting adjustments may vary depending on the fireplace model and installed features. Always refer to the manual for specific instructions tailored to your system. This feature adds versatility and ease of use, making it simple to enjoy your fireplace in any lighting condition. Additionally, the childproofing feature can prevent accidental adjustments, ensuring safety and convenience.

Timer Functions and Countdown Features

The Valor Plus Remote Control offers advanced timer functions and countdown features, allowing you to customize your fireplace experience. Set a timer to turn your fireplace on or off automatically, ensuring it operates according to your schedule. To activate the timer, press and hold the “SET” button until the display flashes, then use the “HIGH” and “LOW” flame buttons to adjust the countdown duration. The remote also features a digital display, showing the remaining time in hours or minutes. Once set, the fireplace will cycle on and off as programmed, providing consistent heat and ambiance. Additionally, the timer can be paired with temperature mode to maintain a specific room temperature during operation. For safety, the timer will automatically shut off the fireplace if no changes are made within a set period. This feature is ideal for energy efficiency and convenience. Always refer to the manual for detailed instructions on configuring timer settings for your specific model.

Childproofing Features and Safety Locks

The Valor Plus Remote Control includes advanced childproofing features and safety locks to ensure safe operation. These features prevent accidental activation of the fireplace, especially in households with children or pets. To activate the childproofing mode, press and hold the “LOW” and “HIGH” flame buttons simultaneously for 5 seconds until a confirmation beep sounds. This will lock all controls, preventing unintended changes to settings. The safety lock feature can also be used to disable the timer and temperature adjustments, providing an additional layer of security. When the safety lock is enabled, the remote will not respond to button presses, and the display will show a locked icon. To deactivate the childproofing mode, repeat the same process of pressing the “LOW” and “HIGH” buttons together for 5 seconds. These features ensure that your fireplace remains safe and secure, even when not in use. Always refer to the manual for detailed instructions on enabling and disabling these safety functions.

Troubleshooting Common Issues

If the remote control fails to synchronize or the fireplace doesn’t respond, check battery levels and ensure proper installation. Verify the receiver is connected correctly and no obstructions block signals. Reset the system by turning it off and on. For persistent issues, refer to the manual or contact support.

Resolving Synchronization Problems

If the remote control and receiver are not synchronizing, start by ensuring both devices have fresh batteries. Low battery power can disrupt communication. Next, check for any physical obstructions between the remote and receiver, as these can block the signal. If issues persist, reset the system by pressing and holding the OFF and high flame buttons simultaneously for 5 seconds until you hear a beep. This process recalibrates the connection. If synchronization still fails, repeat the initial setup process outlined in the manual. Ensure the receiver is properly connected to the fireplace control valve and that no other electronic devices are interfering with the signal. For persistent problems, consult the troubleshooting section of the manual or contact Valor customer support for assistance. Regularly checking and maintaining the remote system can help prevent synchronization issues in the future.
